V012024 • © 2024 Portescap. Specifications subject to change without notice.Dimensions in mmEncodersElectrical Data Characteristics @ 22° C Unit1 Number of Lines Available 16 LPR2 Supply Voltage 3.5 to 15 Volt3 Supply Current Typical 6 mA4 Rise Time 5 μs5 Fall Time 0.2 μs6 Output Signal Two channels square wave7 Electrical Phase Shift 90 ± 40 degree8 Signal Ratio 50 ± 25 %9 Maximum Count Frequency 15 kHz10 Operating Temperature Range: -20 to +85 (-4 to +185) °C (°F)11 Code Wheel Moment of Inertia 0.1 10-7 x kgm212 Weight Varies by motor size. Contact us. g (oz)F16 Integrated Magnetic Encoder12L1 150±3L2ØDØ16910Encoder Type F connections 1. Motor +2. Vcc3. Channel A4. Channel B5. GND 6. Motor -7. NC8. NC9. NC10. NCAvailable on Motor Types 16C 18 17S78 17N78Length with motor mm (in) 18.6 (0.73) 20.2 (0.795) 27.8 (1.09)t1t2t3t5 t4UBUAVcc>0.9 Vcc<0.1 Vcc0tt1 Periodt2/t1 Signal Ratiot3 Phase Shiftt4 Rise Timet5 Fall TimeTypical Encoder Output SignalEncoder Type F Connections1 Motor +2 Vcc3 Channel A4 Channel B5 GND6 Motor -7 NC8 NC9 NC10 NC208
